| Range | Pragma |
|---|---|
| Product or component type | Enclosure |
| Enclosure type | Interface |
| Width | Outside: 200 mm |
| Height | 450 mm |
| Depth | 115 mm |
| Nb of 18 mm modules per row | 13 18 |
| Nb of horizontal rows | 2 |
| Electrical insulation class | Double insulation Class II |
| Provided equipment | 1 x identification label 1 x plain plate per row 1 x front face and back connection |
| Type of door | Without |
| Enclosure mounting | Surface |
|---|---|
| 9 mm pitches | 26 36 |
| Total number of 18 mm modules | 14 |
| Number of plates | 3 for plain plate |
| [In] rated current | 63 A 90 A |
| [Ui] rated insulation voltage | 400 V |
| Type of rail | Without |
| Mounting plate description | Without mounting plate |
| cable entry | Cable or tube Trunking Removable plates Cut-out plates |
| Enclosure material | Back part: technoplastic Front face: technoplastic |
| Colour | Enclosure: white (RAL 9016) Front face: grey (RAL 7004) |
| Market segment | Residential Small commercial |
| Embedding depth | 0 mm |
| Internal depth | 95 mm |
вид
табло тип PRAGMA
материал
PVC
